Mist Eliminators

Overview

The Mist Eliminator is a very large Coalescing type oil removal filter designed to remove Oil and Water Aerosols from a Compressed air system.

Compressed air is directed into the vessel and through the Filter where entrained water and oil aerosols are captured by the fibres.

The captured particles move along the fibres and coalesce into larger droplets, which gravitate to the bottom of the cartridge. Here they fall into the vessel sump and are discharged from the system.

Features

The Oxair Mist Eliminator:

  • Highly Engineered, loosely packed, Glass Fibre Filter Cartridge
  • Housed in a heavy duty AS-1210 or ASME V111 Stamped pressure vessel
  • Flow from 100 SCFM to 10,000  SCFM
  • 100 psi to 500 psi available
  • Removes Oil and Water Aerosols and 100% particles 5 microns and larger
  • Long – Element life
  • Low – Pressure drop 1 psi, (0.07) bar through the life of the element
  • Mist Eliminators offer a low cost way to remove oil and water aerosols from a compressed air system
  • Will gives years of trouble free service before element change out

Note:

Oil Separator Failure Protection
Sized correctly – Will protect your Air System from Large Oil Slugs caused by a Catastrophic Compressor Oil Separator Failure.
